DC SPARG TYPE CLUTCH

Size

TKN1)

Overrunning speeds

Sprag space

NO.

of clips

No.

of sprags

Weight

nimax2)

namax3)

Øa+0.008

Øc± 0.013

emin

Ødmin

Øbmax

[Nm]

[min-1]

[min -1]

[mm]

[mm]

[mm]

[mm]

[mm]

[mm]

[kg]

DC2222G-N

63

8600

4300

22.225

38.885

8.33±0.075

10

50

15

–

12

0.03

DC2776-N

119

6900

3400

27.762

44.422

8.33±0.075

13.5

58

18

–

14

0.055

DC3034-N

124

6300

3100

30.34

47

8.33±0.075

13.5

62

20

–

14

0.06

DC3175(3C)-N

159

6000

3000

31.75

48.41

8.33±0.075

13.5

63

21

3

16

0.06

DC3809A-N

275

5000

2500

38.092

54.752

8.33±0.075

16

71

25

–

18

0.085

DC4127(3C)-N

224

4600

2300

41.275

57.935

8.33±0.075

13.5

75

27

3

18

0.09

DC4445A-N

363

4300

2100

44.45

61.11

8.33±0.1

16

79

29

–

20

0.095

DC4972(4C)-N

306

3800

1900

49.721

66.381

8.33±0.1

13.5

86

33

4

22

0.1

DC5476A-N

525

3500

1700

54.765

71.425

8.33±0.1

16

92

36

–

24

0.11

DC5476A(4C)-N

525

3500

1700

54.765

71.425

8.33±0.1

16

92

36

4

24

0.13

DC5476B(4C)-N

769

3500

1700

54.765

71.425

8.33±0.1

21

92

36

4

24

0.18

DC5476C(4C)-N

990

3500

1700

54.765

71.425

8.33±0.1

25.4

92

36

4

24

0.2

DC5776A-N

604

3300

1600

57.76

74.42

8.33±0.1

16

98

38

–

26

0.11

DC6334B-N

806

3000

1500

63.34

80

8.33±0.1

21

104

42

–

26

0.175

DC7221(5C)-N

675

2600

1300

72.217

88.877

8.33±0.1

13.5

115

48

5

30

0.14

DC7221B-N

1279

2600

1300

72.217

88.877

8.33±0.1

21

115

48

–

30

0.185

DC7221B(5C)-N

1279

2600

1300

72.217

88.877

8.33±0.1

21

115

48

5

30

0.21

DC7969C(5C)-N

2038

2400

1200

79.698

96.358

8.33±0.1

25.4

124

53

5

34

0.28

DC8334C-N

2055

2300

1100

83.34

100.000

8.33±0.1

25.4

132

55

–

34

0.27

DC8729A-N

1250

2200

1100

87.29

103.96

8.33±0.1

16

134

58

–

34

0.165

DC10323A(5C)*-N

1612

1800

900

103.231**

119.891

8.33±0.1

16

155

68

5

40

0.205

DC12334C*-N

4800

1500

750

123.340**

140.000

8.33±0.1

25.4

184

80

–

50

0.4

DC12388C(11C)

4875

1500

750

123.881

142.88

9.50±0.1

25.4

186

80

11

44

0.4
