Rod ends GIL..-DO-2RS

Rod ends GIL..-DO, with internal thread, requiring maintenance, to DIN ISO 12 240-4, left hand thread

Radial loadAxial load in one directionAxial load in two directionsStatic angular error and misalignmentDynamic angular error and misalignmentNot sealedGrease lubrication

  d

mm d2

mm l4

mm

GIL6-DO 6 21 40,5 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL8-DO 8 24 48 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL10-DO 10 29 57,5 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL12-DO 12 34 67 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL15-DO 15 40 81 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL17-DO 17 46 90 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL20-DO 20 53 103,5 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL25-DO 25 64 126 Calculate bearing Download CAD drawing Mounting information/user manuals Send to shopping basket

GIL30-DO 30 73 146,5
